| GENERAL INFORMATION | |
| Space to the Right of the Needle | 14" (356 mm) |
| Workspace Height | 5" (127 mm) |
| Large Centrally Located Color Touch Screen | 10.1" (254 mm) |
| Help Center | |
| File Manager | |
| Multi-function Knobs | |
| LED Sewing Lights | 90 |
| Automatic Needle Threader | |
| Manual Thread Cutters | 3 |
| Camera | |
| BERNINA Pinpoint Laser* | |
| WiFi | |
| BERNINA stitchprecision2 Technology | |
| Stitch Plate Recognition | |
| BERNINA Adaptive Thread Tension | |
| BERNINA Dual Feed | |
| Hook System | BERNINA |
| Jumbo Bobbin with 70% more Capacity | |
| Bobbin Winding while Sewing/Embroidering | |
| Powerful DC Motor | |
| BERNINA Free Hand System (FHS) | |
| Programmable BERNINA Foot Control | |
| Needle Stop Up/Down | |
| Thread-up Command | |
| Automatic Presser Foot Lifter | |
| Automatic Thread Cutter | |
| Adjustable Presser Foot Pressure | |
| Lower and Upper Thread Sensor | |
| Tutorial | |
| Quick Help |
| SEWING AND QUILTING | |
| Maximum Sewing Speed (stitches per minute) | 1,200 spm |
| Maximum Stitch Width | 9 mm |
| Maximum Stitch Length | 6 mm |
| Adjustable Needle Positions | 11 |
| Presser Foot Selection | |
| Customizable Stitch Altering Area | |
| Security Function for Needle and Stitch Plate | |
| Sideways Motion | |
| Tapering | |
| Automatic Buttonhole / Length Measuring System | |
| Manual Multi-step Buttonhole | |
| Adjustable Buttonhole Slit Width | |
| Personal Folder | |
| Temporary Altered Stitch Memory | |
| History Function | 24 |
| Stitch Designer | |
| Creative Consultant Sewing | |
| Pattern Repeat | 1-99 |
| Pattern Begin / Pattern End | |
| Mirror-image function | |
| Elongation | |
| Basting Stitch | Stitch #21 |
| Long Stitch | |
| Jumbo Stitch | |
| Triple Stitch | |
| Undo/Redo in Sewing | |
| Backstepping | |
| BERNINA Integrated Stitch Regulator (BISR) | |
| BSR Foot #42 Enabled | |
| Adjustable minimum stitching speed in BSR/BISR 1 Mode | |
| Adjustment of stitch lengths as stitches per inch (SPI) in BSR/BISR | |
| KickStart Function | |
| Start/Stop Button (stitching without foot control) | |
| Presser Foot Hover Function | |
| Freearm Sewing | |
| Total Number of Sewing Stitch Patterns (incl. alphabets) | 2,927 |
| Alphabets/Monograms | 16/2 |
| Decorative Stitches | 957 |
| Button Sew-On Program | 1 |
| Buttonholes/Eyelets | 17/2 |
| Practical Stitches | 40 |
| Sideways Motion Stitches | 272 |
| Quilting Stitches | 124 |
| Tapering/Banner Stitch Patterns | 44/36 |
| EMBROIDERY | |
| Maximum Embroidery Speed (stitches per minute) | 1,000 spm |
| Embroidery Area | 410 × 305 mm, 16.1“ × 12“ |
| BERNINA Placement Scanner | |
| Freearm Embroidery | |
| Built-in Embroidery Designs | 879 |
| Embroidery Alphabets | 24 |
| Customizable Quilt Designs (BQM files) | 206 |
| On-screen Editing of Designs | |
| Change Design Size Proportionally/Non-Proportionally | |
| Align/Distribute Embroidery Designs | |
| Endless Embroidery | |
| Shape Designer | |
| Color Wheel | |
| Customizable Lettering | |
| QWERTY Keyboard | |
| WordArt | |
| Multi-line Lettering and Align Function | |
| Drag & Drop | |
| Align | |
| Virtual Positioning | |
| Pinpoint Placement with 2-Point and 4-Point Placement | |
| Check Design Size | |
| Group/Ungroup | |
| Move Up and Move Down | |
| Undo/Redo | |
| Adjust Stitch Density | |
| Margin Spacing in Basting | |
| Color Resequence | |
| Stitch Design as Single/Multi-Color | |
| Programmable Jump Stitch Cutting | |
| Smart Secure | |
| Invisible Secure | |
| Thread Away Mode | |
| Creative Consultant Embroidery | |
| Embroider Sewing Stitches | |
| Multi-format Design compatible (EXP, DST, PEC, PES, JEF, PCS, SEW, XXX ) | |
| Customizable Quilt Design Format compatible (BQM, HQF, PAT, PLI, QLI, TAP) | |
| Adjustable Stitch Length (SPI) for Customizable Quilt Designs | |
| Start and Stop Editing | |
| Design transfer to/from BERNINA Embroidery Software 9 via WiFi | |
| Embroidery Design Import/Export via USB Interface | |
| Automatic Hoop Recognition | |
| View Stitch-out Time, Thread Colors, Size, Stitches | |
| BERNINA Stitchout App Compatible | |
| Embroidery Sequence Control | |
| Position Recall | |
| Jumbo, Maxi, Mega and Midi Hoop Compatibility | |
| Medium and Small Clamp Embroidery Hoop Compatibility |
| STANDARD ACCESSORIES | |
| Embroidery Module XL with Smart Drive Technology (SDT ) | |
| BERNINA Precision Presser Feet included | 11 |
| Reverse Pattern Foot #1C | |
| Dual Feed Reverse Pattern Foot #1D | |
| Overlock Foot #2A | |
| Buttonhole Foot with Slide #3A | |
| Zipper Foot #4D | |
| Blindstitch Foot #5 | |
| Button Sew-on Foot #18 | |
| Open Embroidery Foot #20C | |
| Embroidery Foot #26L | |
| BERNINA Stitch Regulator (BSR) #42 | |
| Sideways Motion Foot #40C | |
| Slide-on Extension Table | |
| Knee Lever/Free Hand System (FHS) | |
| Standard Embroidery Hoops Included | 4 |
| Giant Hoop with Template (410 x 305 mm, 16.1" x 12") | |
| Embroidery Hoop Large Oval with Template (255 × 145 mm, 10" × 5.7") | |
| Embroidery Hoop Medium Oval with Template (130 × 100 mm, 5.1" × 3.9") | |
| Embroidery Hoop Small with Template (72 × 50 mm, 2.8" × 2") | |
| 9 mm Stitch Plate with Sensor | |
| Straight/CutWork Stitch Plate with Sensor | |
| 5.5 mm BISR Stitch Plate with Sensor | |
| Machine and Module Dust Cover | |
| Accessory Box |
| DIMENSIONS | |
| Machine footprint (width x length) | 9.5“ x 26.5“ (242 x 673 mm) |
| Embroidery module footprint (width x length) | 25“ x 21.7“ (636 x 550 mm) |
| Weight Machine | 42.3 lb (19.2 kg) |
| Weight Embroidery Module | 15 lb (6.8 kg) |
