Basic Features
| StitchVision Technology | |
| Accessory Storage | |
| Adjustable Presser Foot Pressure | |
| Adjustable Screen Brightness | |
| Automatic Thread Cutter | |
| Branded Series |
Disney
|
| Built-in Languages | |
| Built-in Memory | |
| Display Type |
LCD
|
| LCD Display Size |
10.1"
|
| Feed Dog Points |
7
|
| Lighting Type |
LED
|
| Needle Position Key (Up/Down) | |
| Needle Threading System |
Automatic
|
| Presser Foot Leveling | |
| Quick Set Bobbin | |
| Realist Preview | |
| Stitch Selector Type |
Touch Panel
|
| Thread Sensor |
Bobbin Sensor, Upper Thread Sensor
|
| Thread Sensor On/Off | |
| Wide Table Included |
Optional Accessory
|
| Workspace Area |
14.1" x 5"
|
| Wireless LAN | |
| Multi-Function Foot Controller | |
| Voice Guidance |
Embroidery Features
| Adjustable Embroidery Speed Settings | |
| Adjustable Design Icon Size Setting | |
| Appliqué Creator Function | |
| Automatic Feed Thread Cutting | |
| Built-in Alphabet Fonts |
31
|
| Built-in Embroidery Designs |
1,858
|
| Built-in Embroidery Disney/Pixar Designs |
217
|
| Total Built-in Non-Disney Patterns |
1,641
|
| Bonus Designs on Artspira |
10
|
| Color Shuffling Function | |
| Computer Connectivity | |
| Curved Text On-Screen Editing | |
| Drag and Drop Editing | |
| Embroidery Position Marker | |
| Frame Designs Shapes |
10 Shapes x 14 Stitch Patterns
|
| InnovEye Technology | |
| Maximum Embroidery Area |
11 ⅝" x 18 ¼"
|
| Maximum Embroidery Speed (Stitches Per Minute) |
1,050
|
| Maximum Zoom (in My Design Center) |
1600%
|
| My Design Center | |
| On-Screen Automatic Density Adjustment | |
| On-Screen Editing | |
| On-Screen Help | |
| Pattern Rotating Increments |
0.1 Degree, 1 Degree, 10 Degrees, 90 Degrees
|
| Print and Stitch Technology | |
| Programmable Monochrome Embroidery | |
| Resume Function | |
| Sewing Decorative Stitches with Embroidery Arm Attached | |
| Space Reduction among Embroidery Alphabets | |
| Speed Adjustment | |
| Thread Wiper | |
| Trial Position/Layout Function | |
| Picture Play Embroidery Function |
Sewing
| Automatic Height Adjustment (AHA) | |
| Back to Beginning Key | |
| Built-in Stitch Selections (Stitches) |
877
|
| Buttonhole Styles |
25
|
| Independent Bobbin Winding Motor | |
| Knee Lifter | |
| Maximum Sewing Speed (Stitches Per Minute) |
1,050
|
| Multi-Directional Sewing | |
| My Custom Stitch Feature | |
| Pivot Function | |
| Sideways Sewing | |
| Reinforcement/Reverse Stitches | |
| Stitch Length (mm) |
5mm
|
| Stitch Width (mm) |
7mm
|
| Built-in Sewing Lettering Fonts |
4
|
| Guideline Marker |
In 16 colors
|
Quilting
| Built-in Quilting Stitches |
40
|
| Drop-Feed | |
| Free Motion Quilting Foot | |
| Included Quilting Feet | |
| ISR Intelligent Stitch Regulator |
Accessories Included:
| Zigzag foot “J” | |
| Advanced monogramming foot “N+” | |
| Overcasting foot “G” | |
| Zipper foot “I” | |
| Buttonhole foot “A+” | |
| Buttonhole foot stabilizer | |
| Blind stitch foot “R” | |
| Button fitting foot “M” | |
| 1/4" Piecing foot with guide | |
| Straight stitch foot | |
| Free motion quilting foot “C” | |
| Free motion open toe quilting foot “O” | |
| Free motion echo quilting foot “E” | |
| ISR Intelligent Stitch Regulator | |
| Embroidery foot “W” | |
| Compact dual feed and regular dual feed foot | |
| Couching dual feed foot | |
| Embroidery couching foot “Y” | |
| Yarn guide | |
| Yarn threader | |
| Embroidery frame set, 4" x 4" | |
| Embroidery frame set, 5" x 7" | |
| Embroidery frame set, 10 ⅝" x 10 ⅝" | |
| Embroidery frame set, 11 ⅝" x 18 ¼" | |
| Scanning frame | |
| Embroidery positioning sticker sheets (4) | |
| Dual king spool thread stand | |
| Knee lifter | |
| Grid sheet set | |
| Stabilizer | |
| Dual purpose stylus | |
| Accessory case | |
| Support table | |
| Operation manual | |
| Quick reference guide | |
| Additional accessories included in the box |
Machine Specifications
| Machine Weight |
43.431 lbs.
|
| Machine Footprint |
29.567" L x 13.268" W x 13.78" H
|
