General Features
| LCD Display Size (Diagonal) Inches |
3.6 x 6.0
|
| Display (Number of Colors) |
260,000
|
| Opening Screen | |
| Stitch Select |
Touch Screen
|
| On-Screen Help | |
| Built-in Languages | |
| On-Screen Editing | |
| Lighting |
4 LED Lights
|
| Adjustable Screen Brightness Settings | |
| Thread Tension |
Manual
|
| Needle Threading System |
Advanced – Multi-Needle Style
|
| Easy Bobbin Winding |
On Side of Machine
|
| Adjustable Bobbin Winding Speed | |
| Thread Sensor | |
| Thread Sensor On / Off |
Upper and Bobbin
|
| Automatic Thread Cutter | |
| Vertical Bobbin | |
| Full USB |
1
|
| Computer Connectivity with Update Capability | |
| Media Type |
Several Media via USB
|
Embroidery Features
| Maximum Embroidery Area (X x Y) |
8" x 12"
|
| Maximum Embroidery Speed (Stitches Per Minute) |
1000spm
|
| Standard Included Frames |
2 (12" x 8” and 4" x 4”)
|
| Built-in Brother Embroidery Designs |
495
|
| Built-in Embroidery Lettering Fonts |
33
|
| Built-in Alphabet Designs |
8
|
| Built-in Frame Designs |
10 Shapes x 14 Stitch Patterns
|
| Built-in Border Function and Designs | |
| Thread Wiper | |
| Resume Function | |
| Trial Position/Layout Function | |
| Curving Text on Screen Editing | |
| Multiple-line Text Input and Alignment (Left, Center and Right) | |
| Color Ordering | |
| Pattern Rotating |
1, 10, or 90 Degrees
|
| Drag and Drop Editing | |
| Zoom Function |
Zoom to View Many Designs up to 200% Actual Size
|
| Preview Designs Before Stitching | |
| Programmable Monochrome Embroidery | |
| Basting Stitch Before Embroidery | |
| Stitch Forward Backward |
1, 10, 100, 500
|
| Crosshair 2-Point Positioning Laser | |
| Cap Frame Capability |
Other
| Weight |
68.34 lbs
|
| Footprint |
23.1" L x 19.92" W x 22.24" H
|
Included Accessories
- Embroidery Frame Set, 12" x 8"
- Embroidery Frame Set, 4" x 4"
- Pre-wound Bobbins
- Metal Bobbins
- Seam Ripper
- Needle Plate Cover
- Oiler
- Cleaning Brush
- Thread Hook
- Touch Pen (Stylus)
- Accessory Case
- Operation Manual
- Quick Reference Guide
- Additional Accessories included in the Box
Optional Accessories to Enhance Your Machine
- Universal Cap Frame and Set:
- Embroider more types of hats than before with the easy-to-use ‘scratch-free’ cap frame
- Stitch an industry-leading 35% closer to the brim (6-10mm), depending on the cap
- Easy to attach and release
- Includes one Universal Cap Frame, Hooping Jig, and Driver PRCF5
- Magnetic Sash Frame
- Patent-pending Brother-exclusive Hoopnetic Magnetic Sash Frame
- Hoop and embroider thick materials with ease
- Avoid fabric shifting and the need to rehoop the fabric when connecting designs or embroidering large areas
- Sewing area: 300mm x 200mm PRMS360
- Tubular Frame Table
- Serves as extra support for large projects
- Easy to attach
- Expandable table PRTT1
- Flash Frame M Clamp Magnetic Frame Kits
- Available in ~4" x 4" and ~5" x 7" sizes
- Includes four magnets and frame for each size frame
- Available as ‘Frame’ only or as a ‘Frame and Driver Kit’
- Sewing area: 100mm x 100mm and 130mm x 180mm
- PRVMFM, PRVMFMKIT (~4" x 4")
- PRVMFL, PRVMFLKIT (~5" x 7")
