Specifications
| Integrated Dual Feed | |
| Laser Sewing Guidance | |
| Color Touch Screen |
217 x 136 mm (10.1"), 1280 x 800 resolution (WXGA)
|
| mySewnet™ and WiFi Capabilities | |
| JoyOS ADVISOR™ | |
| Quilting Advisor | |
| Accessory Guide | |
| EXCLUSIVE SEWING ADVISOR® Feature |
Enhanced version within JoyOS ADVISOR™
|
| Exclusive SENSOR SYSTEM™ Technology | |
| deLuxe™ Stitch System | |
| Site Motion Sewing | |
| Directional Sewing (4-Way and 8-Way) | |
| Laser Pictogram Stitches | |
| Sequin Stitches | |
| Pop-Up Stitches | |
| Applique Stitches | |
| Theme Stitches | |
| Straight Stitch Plate with Sensor Technology | |
| Automatic Thread Cutter | |
| Electronic Self-Adjusting Thread Tension | |
| Large Sewing Space |
12" width x 5.5" height (310 x 140 mm)
|
| Stitch Selection |
Touch Screen Image Selection
|
| Utility & Decorative Stitches |
844
|
| Buttonhole Styles |
16 buttonholes, 3 eyelets, Sew-on button program
|
| My Stitches Menu (permanent memories) |
100 MB memory available using WiFi
|
| Needle Positions |
37
|
| Light System |
LED technology with light guide optics
|
| Quick Help |
Yes, plus link to manual
|
| Built-In Needle Threader |
Automatic
|
| Stitch Width |
9 mm
|
| Extended Dual Stitch Plate Guide Lines |
65 mm (2.5") on both sides of the needle
|
| Free-Motion Modes |
3
|
| Programmable Sewing Fonts |
5
|
| Choose On-Screen Color Scheme | |
| Mirror End-to-End / Side-to-Side | |
| Stitches on Screen in Real Size | |
| Feed Teeth Drop |
Automatic
|
| Permanently Lubricated | |
| Electronic Speed Control |
5 speeds
|
| Snap-On Presser Feet Included |
11
|
| Larger Bobbin |
30% larger
|
| Bobbin Winds from the Needle | |
| Telescopic Thread Stand | |
| Twin Needle Safety and Stitch Width Safety | |
| Top Thread Sensor | |
| Bobbin Thread Sensor | |
| FIX Function | |
| STOP Function | |
| Needle Stop Up/Down | |
| Instant and Permanent Reverse |
2 reverse buttons
|
| START/STOP Function (sew without foot control) | |
| Multi-Function Foot Control Compatible | |
| USB Connectivity |
2 USB Ports
|
| Built-In Spool Pins |
2
|
Other
| Machine Dimensions |
28.7" x 16.9" x 22.83" (73 × 43 × 58 cm)
|
| Machine Weight |
48.5 lbs (22 kg)
|
